Double acting
Size	Air supply pressure(bar/)
	3.0	4.0	5.0	6.0	7.0	8.0
	Torque table (Nm)
VS-032DA	4.6	6.1	7.6	9.2	10.7	12.2
VS-052DA	12.0	16.0	20.0	24.0	28.0	32.0
VS-063DA	21.7	28.9	36.0	43.4	50.6	57.8
VS-075DA	30.0	40.0	50.0	60.0	70.0	80.0
VS-083DA	46.8	62.4	78.0	93.6	109.2	124.8
VS-092DA	67.6	90.1	112.6	135.2	157.7	180.2
VS-105DA	97.7	130.3	162.9	195.5	228.0	260.6
VS-125DA	150.5	200.6	250.8	301.0	351.1	401.3
VS-140DA	260.7	347.6	433.8	521.4	608.3	695.2
VS-160DA	397.2	529.6	662.0	794.4	926.8	1059.2
VS-190DA	640.2	853.6	1067.0	1280.4	1493.8	1707.2
VS-210DA	798.0	1064.0	1330.0	1596.0	1862.0	2128.0
VS-240DA	1154.3	1539.0	1923.8	2308.5	2693.3	3078.0
VS-270DA	1755.0	2340.0	2924.0	3510.0	4095.0	4680.0
VS-300DA	2291.4	3055.2	3819.0	4582.8	5346.6	6110.4

sanitary ball valve 3-way with VS series rack pinion pneumatic actuator
Selection of pneumatic actuator: matching size for reference only, valve torque plus 25% safety factor
Size	Valve Torque in.lbs	valve torque*1.25	Double Acting Actuator	Actuator Torque (in.lbs) 5bar	Spring Return Actuator	Actuator Torque (in.lbs) 5bar FC
1/2"	79	98.75	VS-052DA	177	VS-052SR10	70-104
3/4"	85	106.25	VS-052DA	177	VS-052SR10	70-104
1"	110	137.5	VS-052DA	177	VS-075SR10	190-318
1-1/2"	290	362.5	VS-075DA	515	VS-092SR10	407-574
2"	680	850	VS-092DA	997	VS-125SR10	1018-1497
2-1/2"	1085	1356.3	VS-105DA	1441	VS-140SR10	1538-2247
3"	1597	1996.3	VS-125DA	2555	VS-160SR10	2379-3388
4"	1780	2225	VS-125DA	2555	VS-160SR10	2379-3388

sanitary ball valve 3-way with VS series rack pinion pneumatic actuator
Size	valve torque*1.25	Valve Top Connection (mm)	Double Acting Actuator	Actuator Torque (in.lbs) 5bar	Spring Return Actuator	Actuator Torque (in.lbs) 5bar FC
1/2"	90	9	VS-052DA	177	VS-052-SR10	70-104
3/4"	100	9	VS-052DA	177	VS-052-SR10	70-104
1"	140	11	VS-052DA	177	VS-063-SR10	190-318
1-1/2"	240	14	VS-063DA	320	VS-083-SR10	264-359
2"	480	14	VS-075DA	515	VS-105-SR10	562-857
2-1/2"	650	17	VS-083DA	631	VS-125-SR10	1018-1497
3"	1150	17	VS-105DA	1441	VS-140-SR10	1538-2247
4"	1400	22	VS-105DA	1441	VS-140-SR10	1538-2247

Pneumatic High Pressure Valve VS-063DA / Stainless Steel Actuated Ball Valves
